3ZX90-Plunger Pump-Wuxi Haiyan High-pressure Valve Factory

3ZX90

Stroke Length (mm) ：90
Crankcase Oil Capacity (L)：18.8
Pump Weight (KG)： 535
Recommended SPM for Continuous Duty： ≤370
Standard Gear Ratio：4.00
Optional Gear Ratio：3.16

	Strokes per Minute	75	125	175	225	275	325	375	425	475	525
	Input Power (kw)	16.7	27.8	38.9	50.0	61.1	72.2	83.3	94.4	105.5	116.6
Plunger Size(mm)	Rated Pressure(bar)	Rated Capacity(L/min)
30	623	14.3	23.9	33.4	42.9	52.5	62.0	71.6	81.1	90.7	100.2
35	457	19.5	32.5	45.5	58.4	71.4	84.4	97.4	110.4	123.4	136.4
40	350	25.4	42.4	59.4	76.3	93.3	110.3	127.2	144.2	161.2	178.1
45	277	32.2	53.7	75.1	96.6	118.1	139.6	161.0	182.5	204.0	225.4
50	224	39.8	66.3	92.8	119.3	145.8	172.3	198.8	225.3	251.8	278.3
52	207	43.0	71.7	100.3	129.0	157.7	186.4	215.0	243.7	272.4	301.0
55	185	48.1	80.2	112.3	144.3	176.4	208.5	240.6	272.6	304.7	336.8
58	167	53.5	89.2	124.8	160.5	196.2	231.8	267.5	303.2	338.8	374.5
60	156	57.3	95.4	133.6	171.8	209.9	248.1	286.3	324.4	362.6	400.8
62	146	61.1	101.9	142.7	183.4	224.2	264.9	305.7	346.4	387.2	428.0
63	141	63.1	105.2	147.3	189.4	231.5	273.5	315.6	357.7	399.8	441.9
65	133	67.2	112.0	156.8	201.6	246.4	291.2	336.0	380.8	425.6
68	121	73.5	122.6	171.6	220.6	269.7	318.7	367.7	416.7
70	114	77.9	129.9	181.8	233.8	285.7	337.7	389.7	441.6

Strokes per Minute

125

175

225

275

325

375

425

475

525

Input Power (kw)

16.7

27.8

38.9

50.0

61.1

72.2

83.3

94.4

105.5

116.6

Plunger Size(mm)

Rated Pressure(bar)

Rated Capacity(L/min)

623

14.3

23.9

33.4

42.9

52.5

62.0

71.6

81.1

90.7

100.2

457

19.5

32.5

45.5

58.4

71.4

84.4

97.4

110.4

123.4

136.4

350

25.4

42.4

59.4

76.3

93.3

110.3

127.2

144.2

161.2

178.1

277

32.2

53.7

75.1

96.6

118.1

139.6

161.0

182.5

204.0

225.4

224

39.8

66.3

92.8

119.3

145.8

172.3

198.8

225.3

251.8

278.3

207

43.0

71.7

100.3

129.0

157.7

186.4

215.0

243.7

272.4

301.0

185

48.1

80.2

112.3

144.3

176.4

208.5

240.6

272.6

304.7

336.8

167

53.5

89.2

124.8

160.5

196.2

231.8

267.5

303.2

338.8

374.5

156

57.3

95.4

133.6

171.8

209.9

248.1

286.3

324.4

362.6

400.8

146

61.1

101.9

142.7

183.4

224.2

264.9

305.7

346.4

387.2

428.0

141

63.1

105.2

147.3

189.4

231.5

273.5

315.6

357.7

399.8

441.9

133

67.2

112.0

156.8

201.6

246.4

291.2

336.0

380.8

425.6

121

73.5

122.6

171.6

220.6

269.7

318.7

367.7

416.7

114

77.9

129.9

181.8

233.8

285.7

337.7

389.7

441.6
